Introduction

As some of you may know matrix multiplication is associative (a.k.a. all the parenthesizations give the same result). But when you carry out the computation you have to choose some order. But associativity makes this irrelevant, right?

Consider:

Matrix = np.ndarray

@dataclass
class Parenthesization:
    left: Parenthesization | Matrix
    right: Parenthesization | Matrix

def random_matrices(n: int) -> list[Matrix]:
    dims = [random.choice((1, 100)) for _ in range(n + 1)]
    return [np.random.randn(dims[i], dims[i + 1]) for i in range(n)]

def random_parenthesization(matrices: list[Matrix]) -> Parenthesization | Matrix:
    if len(matrices) == 1:
        return matrices[0]
    k = random.randint(1, len(matrices) - 1)
    left = random_parenthesization(matrices[:k])
    right = random_parenthesization(matrices[k:])
    return Parenthesization(left, right)

def get_product(node: Parenthesization | Matrix) -> Matrix:
    if isinstance(node, Matrix):
        return node
    return get_product(node.left) @ get_product(node.right)

if __name__ == '__main__':
    matrices = random_matrices(100)
    parenthesizations = [random_parenthesization(matrices) for _ in range(1_000)]
    performance_barplot(parenthesizations, get_product)

TLDR: For a given product of matrices, generate a bunch of random parenthesizations and see how long they take to compute.

Which gives us:

   420-   600 ms │ ████
   600-   780 ms │ ██████████████████
   780-   960 ms │ ████████████████████████████
   960-  1130 ms │ ████████████████████████████████████████
  1130-  1310 ms │ █████████████████████████████
  1310-  1490 ms │ ██████████████████████████
  1490-  1670 ms │ ███████████████████
  1670-  1840 ms │ ████████████
  1840-  2020 ms │ ████████████
  2020-  2200 ms │ ██████
  2200-  2380 ms │ ███
  2380-  2550 ms │ ███
  2550-  2730 ms │ ██
  2730-  2910 ms │ █
  2910-  3090 ms │
  3090-  3260 ms │ █

Holy mother of performance-variance-for-semantically-equivalent-expressions!

Why does this happen??

Different Parenthesization => Different Dimensions! Multiplying an X by Y matrix with a Y by Z matrix takes about O(XYZ) scalar ops (XYZ multiplications, X(Y-1)Z additions). So on the LHS each pairwise product takes 1 op, in the RHS about 2 million!

Oh yeah that makes sense! But how do we fix it? Boringly, with some DP:

Solution V1

def optimal_parenthesization(matrices: list[Matrix]) -> tuple[int, Parenthesization | Matrix]:
    n = len(matrices)
    if n == 1:
        return 0, matrices[0]

    dims = [matrices[0].shape[0]] + [m.shape[1] for m in matrices]
    mult_cost = lambda i, k, j : dims[i] * dims[k + 1] * dims[j + 1]

    @cache
    def solve(i: int, j: int) -> tuple[int, Parenthesization | Matrix]:
        if i == j:
            return 0, matrices[i]

        best_cost, best_tree = float("inf"), None

        for k in range(i, j):
            left_cost,  left_tree  = solve(i, k)
            right_cost, right_tree = solve(k + 1, j)

            cost = mult_cost(i, k, j)

            total_cost = left_cost + right_cost + cost
            if total_cost < best_cost:
                best_cost = total_cost
                best_tree = Parenthesization(left_tree, right_tree)

        return best_cost, best_tree

    return solve(0, n - 1)

TLDR: To find the optimal parenthesization: for all the ways to split the list into 2 contiguous chunks, recursively find the cost of the 2 sub-chunks, and add them to the cost of doing the top-level multiplication. Then find the minimum value: that is the optimal parenthesization!

But, ew. Now our code logic is tangled up with implementation details concerning runtimes. How do we address this?

Solution V2

Ideally something like this:

But here’s the problem: the matmul¹ is supposed to always be a single matrix (the product of all the matrices up to that point). But now you are representing it as a tree (of parenthesis)! Solution: just collapse it down to a single matrix when the user “looks” at it! (a.k.a. when the explicit value of the matrix is needed: as long as we keep multiplying, we can just keep building up the list). So we can do something like this!

@dataclass
class LazyMat:
    matrices: list[Matrix] = field(default_factory=list)

    def __matmul__(self, other: Matrix | LazyMat) -> LazyMat:
        if isinstance(other, Matrix):
            return LazyMat(self.matrices + [other])

        if isinstance(other, LazyMat):
            return LazyMat(self.matrices + other.matrices)

        raise NotImplementedError

    def __rmatmul__(self, other: Matrix | LazyMat) -> LazyMat:
        if isinstance(other, Matrix):
            return LazyMat([other] + self.matrices)

        if isinstance(other, LazyMat):
            return LazyMat(other.matrices + self.matrices)

        raise NotImplementedError

    def value(self) -> Matrix:
        _, tree = optimal_parenthesization(self.matrices)
        prod = get_product(tree)
        self.matrices = [prod]
        return prod

    def __array__(self, dtype=None):
        out = self.value()
        return np.asarray(out, dtype=dtype) if dtype is not None else out

So now we passively build up the tree each time we do a matmul, and use .value() when we need the matrix itself. Cool!

Results

Now for the speedup over eager:


def random_matrices(n: int) -> list[Matrix]:
    dims = [random.randint(10, 1000) for _ in range(n + 1)]
    return [np.random.randn(dims[i], dims[i + 1]) for i in range(n)]

def naive_product(chain):
    """(((A @ B) @ C) @ …)."""
    out = chain[0]
    for m in chain[1:]:
        out = out @ m
    return out

def lazy_product(chain):
    """Wait to evaluate, then do the optimal parenthesization"""
    acc = LazyMat()
    for m in chain:
        acc = acc @ m
    return acc.value()

def bench(fn, mats, runs=10):
    t0 = time.perf_counter()
    for _ in tqdm(range(runs)):
        fn(mats)
    return (time.perf_counter() - t0) / runs

if __name__ == "__main__":
    random.seed(0); np.random.seed(0)

    mats = random_matrices(100)

    t_naive = bench(naive_product, mats)
    t_lazy  = bench(lazy_product,  mats)

    print(f"Naïve left‑to‑right : {t_naive*1e3:7.1f} ms")
    print(f"Lazy optimal        : {t_lazy*1e3:7.1f} ms")
    print(f"Speed‑up            : {t_naive/t_lazy:7.1f}×")

Naïve left‑to‑right :  2298.8 ms
Lazy optimal        :   227.0 ms
Speed‑up            :    10.1×

But it doesn’t have to end there! We can also act lazily with respect to a whole bunch of other operators. This allows us to do 2 things:

Right now, each non-matmul operation forces us to compute the entire tree: the more operators we support, the more we can keep the lazy representation!
More operators => more opportunities for optimizations. E.g. if matrix addition is supported, we can do this: AB+AC -> A(B+C)!

See part 2 here.

Conclusion

Delaying execution of operations via lazy evaluation means that our optimizations can look at the entire expression at once, rather than at sigle operations at a time. [OTHER]

Matrix multiplication ↩
